Transformer Test
GF1061 Portable Precision Current Transformer Testing CT PT Analyzer
GF1061 portable CT PT analyzer is mainly used for field or lab testing, it can finish the measurements (M) and protection (P) class CT, PT and TYP class CT. Adopt 7 inch touch TFT LCD, self-equipped mini type printer supporting field printing; supporting to use USB flash disk to download data or RS232 port to PC control. This model GF1061 CT PT Analyzer is the most complete and easy-to-use testing system for protection and metering CTs according to IEEE C57.13 and IEC60044 & IEC61869 standards...
-
GF1061CT Portable CT Analyzer With Printer
- CT burden test
- CT polarity test
- CT excitation test
- CT phase error test
- CT DC resistance test
- CT ratio test : 1-50000
-
GF1061PT Portable Voltage transformer tester
- Weight 4.8KG
- PT phase error 1min
- 7 inch touch TFT color LCD
- Testing various types of PT
- Test PT quickly in one minute
- PT ratio: 1-30000, class 0.05
-
GF1061CVT Portable Capacitor Voltage Transformer Tester
- CVT burden test
- CVT polarity test
- CVT ratio error test
- CVT phase error test
- CVT DC resistance test
- CVT capacitance partial voltage ratio test
-
GF106 CT PT TESTER
- With mini type printer
- Accuracy 0.05% or 0.1%
- CT: 1-30000/PT:1-10000
- In-built PT test function
- 3000groups test data logger
- IEC60044/IEC61869/ANSI C57.13
-
GF106T Portable CT PT analyzer
- 0-1000A/0-2500V
- CT: 25000/5A-5000/1A
- Storage 3000groups data
- Ratio, phase error testing
- PT: 1-500KV/100V/120V/220V
- Auto test knee point voltage
-
TEST-901 PRIMARY CURRENT INJECTION TEST SET
- CT ratio test
- Accuracy 0.5%
- Load capacity 5KVA
- With timer & binary input
- Primary current range 0-1100A
- Circuit breaker active time test
-
TEST-902 PRIMARY CURRENT INJECTION TESTER
- Accuracy class 0.5
- Load capacity 12KVA
- Current resolution 0.1A
- With timer & binary input
- Secondary current range 0-6A
- Primary current range 0-2200A
-
TEST-903 Electrical 3000A Primary Current Injection Test Equipmen
- Accuracy class 0.5%
- Load capacity 15KVA
- CT ratio test function
- Temperature rise testing
- With timer & binary input
- Primary current range 0-3300A
-
TEST-905 5000A Circuit Breaker Testing Primary Current Injection Test System
- Accuracy class 0.5
- Load capacity 30KVA
- CT ratio test function
- Current resolution 0.1A
- Temperature rise testing
- Primary current range 0-5500A
-
TEST-200 200A Portable Primary Current Injection Test Kit
- Accuracy class 0.2%
- Current range 0-250A
- Voltage range 0-250V AC
- Voltage range 0-300V DC
- Current resolution 0.1A
- Voltage resolution 0.1V
-
GF1061R INSTRUMENT TRANSFORMER TURNS RATIO
TEST SET
- 6 inch LCD
- Weight <5KG
- Phase angle 0-90°
- PT ratio: 0.8-10000
- CT ratio: 0.8-50000
- Store 3000 groups of data
